Knife Gate Valve CF8 4 Inch 150LB Lug Type Handwheel

The 6 inch stainless steel gate valve, designed as per MSS-SP-81, has the lug type connection per Class 150 and electric actuator. Quick Detail Type Knife Gate Valve Size 6'' Design Pressure ANSI 150 Construction Knife Type Gate Valve ConnectionType Lug Type OperationType Electric Actuator Body Material ASTM A351 CF8 TrimMaterial SS304 Design Code MSS SP81 Medium Water, Oil and Gas Origin China Related Knowledge What are knife gate valves used for? Knife gate valves are originally designed for paper industry. The knife gate valve is especially applicable for heavy liquids with solid particulates, like slurry liquid, that are most corrosive, erosive and abrasive. Compared to wedge gate valve, the knife gate valve has a shorter end to end dimension and lighter weight. Plus, the knife valve has a more sharpened disc to cut through slurry and viscous medium. Both wedge gate valve and knife gate valve can only be used for on-off function not for regulating the flow. Dervos Customer Service With Dervos customer service, you will not have any concern before, during and after buying valves. Pre-sales We will reply on time and also provide technical support upon your request. Order We will check the production details with factory and customers. Sales confirmation will also be sent. During production, we will also send weekly report to let you know the order status. Before shipment, delivery note will be sent to let you know the situation. 18 Month warranty Dervos is always responsible for their products. We will provide 18 months warranty to let our customers without concern.

The stainless steel knife gate valve is designed with DN800 PN6 flange end and gearbox operation. The soft seated knife gate valve has a unidirectional sealing. Quick Detail Type Gate Valve Size DN800 Design Pressure PN6 Construction Unidirectional, Soft Seated ConnectionType Flange End OperationType Gearbox Operated Body Material CF8M DiscMaterial SS316L StemMaterial SS316 SeatMaterial PTFE Design Code MSS SP81 Medium Water, Oil and Gas Origin China  Dimension Checking Pressure Tesing

The knife gate is a bi-directional lug type valve designed according to MSS-SP-81 and for industrial service applications. The design of the body and seat assures non-clogging shut off on suspended solids in industries.

The DN150 PN10 unidirectional knife gate valve features a single piece, stainless steel body design provides tested performance in applications ranging from general purpose to severe media.

4" 150LB wafer check valve is made according to API 594 standard. The valve body is made of A351 CF8M+STL. It has the structural characteristics of double disc. Its connection mode is wafer.

The DN32 JIS 5K globe valve is suitable for marine application. The bronze globe valve is handwheel operated with FF flange. Quick Detail Type Marine Globe Valve Size DN 32 Design Pressure 5K Connection Type FF Flange Design Code JIS F7301 Face to Face JIS B2002 Body Material Bronze Trim Material Bronze Application Water, Oil, Gas Purchasing System Late delivery time become a common issue in 2018. However, Dervos keep more than 90% on-time delivery, so how do we achieve that? It owns our purchasing department.  How do we react to a delay crisis? -Visit the factory everyday and supervise on site -Initiate related resources, such as machining workshops and skilled workers to help on expediting production What benefits could we do for you by keeping on-time delivery? -Avoid penalty from end user -Accumulate reputation -Gain client’s trust FAQ 1. Do you have your own foundry or forge shop?  No, but we have an approved list of foundries over the past decade of casting inspections, which can make sure that our castings are of good quality and all the raw materials are traceable.  2. Can you do NDE Capability radiography, MT, UT, LP? Of course, we can do all these tests upon our clients, but there will be additional charge to these tests. 3. What kind of test will you do for each order? After valve assembly, we will do hydraulic test for shell & sealing and air test. Plus, we will do dimension checking (face to face dimension, flange dimension) as per assembly drawing and standards.

The DN80 PN25 gate valve is designed as per EN 1984. With common parts of a valve, like bolted bonnet, outside yoke and handwheel, its body is made of 1.0619 and 13Cr. Other parts including body, bonnet,seat and others are promised to be traceable.   Quick Detail Type Gate Valve Nominal Diameter DN80 NominalPressure PN25 Construction B.B ; OS&Y Connection RF Operation Handwheel Design & Manufacture EN 1984 End to End  DIN 3202 Flange End Dimension EN 1092-1 Test & Inspection  EN 12266-1 Temperature Range -29℃~+425℃ Body Material 1.0619 +STL Wedge Material 1.0619 +13Cr Media W.O.G. Company Brief Introduction  Specializing in valve industry over 10 years, Dervos becomes the leading vendor of gate, globe, check, ball, butterfly, plug valves and strainers. We serve oil and gas user such as LUKOIL, MOL, YPF with local partners.   Dervos show its advantages in: 1. Our partnerships with tens of stable suppliers allow us to provide customers with a wide range of high-quality products at a competitive price. 2. Each order is under strict quality control with inspection reports before delivery. 3. We value delivery time as much as our customers do. With the powerful purchasing system, we follow each order closely to secure on-time delivery. 4. One-stop solutions will be offered in a timely manner

1" 300LB gate valve is made according to API 602 and ASME B16.34 standard. The valve body is made of A350-LF2. It has the structural characteristics of bolt cover, exposed rod, OS&Y, reduced diameter. Its connection mode is RF integral flange. And it has polished rod operation mode.

DN100 PN40 butterfly valve is made according to EN 593 standard. The valve body is made of ASTM A216 WCB. It has the structural characteristics of three eccentric, bidirectional one to one pressure test. Its connection mode is EN1092-1 B. And it has turbine operation mode.

The PTFE fully lined butterfly valve is made of cast iron body and with gearbox operation. The 14 inch flanged valve has concentric type structure. Quick Detail Type Butterfly Valve Size 14'' Design Pressure 150LB Construction Concentric Type, PTFE Lined Connection Type Double Flanged Operation Gear Operated Design Code API 609 Face to Face ASMEB16.10 End Connection ASMEB16.5 Test & Inspection API 598 Body Material Cast Iron GGG40 Temperature Range -15℃~+150℃ Application Water, Oil, Gas Related Knowledge What is the advantage of fully lined butterfly valve? The main advantage of lined butterfly valve is that it can handle abrasive and corrosive application at a relatively lower cost. The PTFE or PFA flexible seat provide a zero leakage sealing performance. Plus, the lined material PTFE has strong corrosion resistance, stable performance, low friction coefficient, which make the lined butterfly valve has a long service life. How does Dervos control quality of raw material? Raw material plays an important role in product quality. Likewise, casting and forging affect valve quality a lot. That is why Dervos pay a lot of attention to foundries. We have an approval list of foundries and classify them by certificates, scale, process and materials. To meet different requirements from customers, we could even appoint suitable foundries for our customers.

The inverted bucket type steam trap is known as the most reliable steam trap. The DN20 WCB inverted bucket steam traps are used in steam heating systems to stop steam from draining out, so choosing the right trap can help steam heating equipment work more efficiently.

Line blinds are utilized in pipeline systems when there is a need for either complete closure or unimpeded flow transition without a significant drop in pressure. The THD (Through-Hole Design) enables swift and seamless adjustments in position. The THD-slide variant boasts a multi-bolt configuration, making it easier to operate with reduced face-to-face dimensions. The inclusion of extra body bolts renders this style particularly well-suited for high-pressure applications.
