GATE VALVE

A gate valve, also known as a sluice valve, is a valve that opens by lifting a barrier (gate) out of the path of the fluid.” The main function of a gate valve is to cut off the medium. Dervos has been supplying gate valves for more than 10 years, from API 600 wedge gate valve, API 6D through conduit gate valve, API 6A wellhead gate valve to knife gate valve, pressure seal gate valve, bellow seal gate valve, expanding gate valve, carbon steel gate valve, stainless steel gate valve to cast iron gate valve and etc.


Gate Valve Category

  • #
    Steel Gate Valve
    Available in Cast Steel, Forged Steel, Alloy Steel bodies with bolted or flanged bonnet, featuring:
    · Size range: 2'' to 48'' (DN50 to DN1200)
    · Pressure range: Class 150 to 2500 (PN16 to PN420)
  • #
    Ductile Iron Gate Valve
    Body with bolted or flanged bonnet, featuring:
    · Size range: 2'' to 36'' (DN50 to DN900)
    · Pressure range: Class 150 to 300 (PN16 to PN40)
  • #
    Cast Iron Gate Valve
    Body with bolted or flanged bonnet, featuring:
    · Size range: 2'' to 36'' (DN50 to DN900)
    · Pressure range: Class 125 to 150 (PN10 to PN16)
  • #
    Knife Gate Valve
    Wedge-type or sharp-edged gate, featuring:
    · Size range: 2'' to 48'' (DN50 to DN1200)
    · Pressure range: Class 150 to 300 (PN16 to PN50)
  • #
    Through Conduit Gate Valve
    Full bore design for slurry and viscous media, featuring:
    · Size range: 4'' to 48'' (DN100 to DN1200)
    · Pressure range: Class 150 to 300 (PN16 to PN50)
  • #
    Pressure Seal Gate Valve
    Bolted bonnet with pressure seal design, featuring:
    · Size range: 4'' to 48'' (DN100 to DN1200)
    · Pressure range: Class 600 to 2500 (PN100 to PN420)
  • #
    Cryogenic Gate Valve
    Low-temperature design for -196°C to -50°C, featuring:
    · Size range: 2'' to 36'' (DN50 to DN900)
    · Pressure range: Class 150 to 900 (PN16 to PN160)
  • #
    Wellhead Gate Valve
    API 6A compliant, for oil & gas applications, featuring:
    · Size range: 2'' to 24'' (DN50 to DN600)
    · Pressure range: Class 5000 to 20000 psi
  •


Size, Pressure and Material Range of Gate Valves



Size: from 2'' to 72'' (from DN 50 to DN 1800)

Pressure: from Class 150 to Class 2500 (from PN 10 to PN 420)

Material: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Stainless Steel, Super Duplex, Nickel Alloy, Cast Iron, Ductile Iron


Features of Gate Valves



1.Low Fluid Resistance for Smooth Flow

The straight-through flow path ensures minimal pressure loss, making gate valves suitable for large-diameter pipelines and long-distance fluid transmission.



2.Reliable Shut-Off Performance

With a wedge, parallel, or flexible gate design, gate valves deliver tight sealing when fully closed, ensuring dependable isolation even under high pressure.



3.Simple Open/Close Mechanism

Operated by turning the handwheel or actuator to raise or lower the gate, the valve achieves complete separation of the flow with clear open and close positions.



4.Full-Open Design with No Flow Obstruction

When fully opened, the gate retracts completely out of the flow passage, providing an unobstructed full-bore design ideal for pigging and minimal erosion.



5.Automation-Compatible

Gate valves can be equipped with electric, pneumatic, or hydraulic actuators to support remote control and integration into automated pipeline systems.



6.Multiple Operation Modes Available

Electric actuator gate valve, gear-operated gate valve, pneumatic gate valve, hydraulic operated gate valve, manual gate valve, rising stem and non-rising stem configurations, etc.



7.Various Connection Ends Available

Flanged ends connection, threaded connection, NPT threaded gate valve, butt-weld end, socket-weld end, wafer-type connection, lug-type connection, etc.


Gate Valve Application



1.Oil and Gas Industry

Gate valves for the oil and gas industry, suitable for crude oil and natural gas transmission pipelines, wellhead isolation, block valve stations, and long-distance trunk lines.



2.Chemical and Pharmaceutical Industry

Suitable for corrosive, high-temperature, or high-pressure media, and widely used in process pipelines, storage tanks, and chemical isolation systems.



3.Power Industry

Ideal for high-temperature and high-pressure steam pipelines, boiler feed-water systems, cooling water networks, and auxiliary power plant equipment.



4.Water Treatment and Environmental Protection Projects

Suitable for municipal water supply systems, wastewater treatment, desalination plants, and large-diameter pipeline isolation in environmental engineering.



5.Building and HVAC Systems

Used in building water supply networks, fire-fighting systems, heating loops, and central air-conditioning pipeline isolation.





Gate Valve Application Cases
DERVOS supports ECOFUEL’s innovative clean-energy project in Canada, supplying 136 sets of high-quality valves to enable sustainable diesel production from solid waste. ECOFUEL recognizes DERVOS for its reliability, customization capability, and outstanding performance in this landmark green-technology initiative. READ MORE

Gate Valve FAQS



1. What is a gate valve used for?

A gate valve is used for fully opening or fully shutting off fluid flow in pipelines.



2.Gate valve price DN100 PN16?

Prices vary by material and standard — request a quotation for exact pricing.



3.Rising stem gate valve vs non-rising stem gate valve?

One-line answer: Rising stem shows position; non-rising stem saves space — full types available.



4.Which is better for my pipeline: cast steel or forged steel gate valves?

Forged steel is ideal for smaller, high-pressure valves, while cast steel suits larger diameters and moderate pressures. Explore our product range to find the right choice.



5.What types of gate valves are recommended for water pipelines with different pressure ratings?

We provide DN50–DN1200 gate valves with PN10–PN40 ratings suitable for reliable water pipeline isolation. Detailed dimensions and models are available online.



6.Which gate valves can be used safely in oil and gas pipelines?

Our API-compliant gate valves ensure safe operation under high-pressure oil and gas conditions. Visit our site to check materials, sizes, and pressure ratings.
