Project Type: Safety upgrade of an in-service high-pressure pipeline
Client: A major oil & gas company in Russia (Siberia region)
Application: Isolation and maintenance blind-off for high-temperature steam / hot oil pipelines
Pressure Rating: 600LB (Class 600)
Core Product: F22 Swing-Type Line Blind Valve (note: swing-type retained; see clarification below)
Commissioning: Q3 2024
Data Collection Period:12 months
The pipeline system operates at pressures up to 600LB, with media including high-temperature steam (up to 520°C) and hot oil. The valve is required to provide highly reliable sealing performance under high-pressure conditions.
Maintenance isolation and blind-off operations must be carried out safely without shutting down the system. However, conventional line blind valves presented the following issues under large-diameter and high-pressure conditions:
Difficult operation:
Each blind-off operation required pipeline depressurization. The average operation time was approximately 45 minutes, requiring coordination of three operators.
Leakage risk:
Under high-pressure thermal cycling, sealing surfaces were prone to deformation. Two minor leakage incidents had previously resulted in unplanned shutdowns.
Harsh environment:
In Siberia, winter temperatures can drop to -45°C, while pipeline surface temperatures exceed 60°C in summer. Frequent industrial vibration places high demands on valve structural strength and durability.
High maintenance cost:
The existing valves required inspection and maintenance every three months, with annual maintenance costs exceeding USD 120,000.
A swing-type line blind valve manufactured in F22 material was provided, designed in accordance with ASME B16.34, ensuring high-pressure and high-temperature resistance while accommodating mechanical stress in industrial environments.
The valve adopts a swing-type mechanism, allowing the blind plate to rotate smoothly within the valve body during operation. This enables safe switching between isolation and flow positions without requiring pipeline depressurization, reducing operational risks.
The valve body material can be selected as F11 or F22. With high-temperature alloy properties, stable sealing performance is maintained under high-temperature steam or hot oil service.
An RTJ (Ring-Type Joint) flange connection is applied, facilitating installation in large-diameter pipelines. In addition, a mechanical interlock is incorporated to prevent misoperation and enhance on-site safety.
Swing-Type Design for Online Isolation
The blind plate rotates smoothly within the valve body, eliminating the need for valve disassembly or pipeline depressurization. Each isolation / flow switching operation can be completed within approximately 10 minutes by a single operator.
F22 High-Temperature Alloy for Extreme Service Conditions
F22 material (containing Cr 2.00–2.50% and Mo 0.90–1.10%) maintains high creep rupture strength at temperatures up to 520°C. It also meets low-temperature impact test requirements down to -46°C, making it suitable for the full annual temperature range in Siberia.
Enhanced Sealing Reliability
Spring-loaded sealing surfaces automatically compensate for dimensional changes caused by thermal cycling. After 500 thermal cycles, the leakage rate remains better than ISO 5208 Rate A (zero visible leakage).
Anti-Misoperation Design
Equipped with a mechanical interlock and position indicator to prevent incorrect operation under pressurized conditions, improving on-site operational safety.
Compared with conventional line blind valves, the F22 swing-type solution demonstrates the following performance improvements:
● Operation time (per isolation): reduced from 45 minutes (with depressurization required) to 10 minutes (online switching)
● Personnel required: reduced from 3 operators to 1 operator
● Leakage rate (over 12 months of operation): from 2 recorded minor leakage incidents to zero leakage
● Maintenance interval: extended from every 3 months to ≥18 months
● Operating temperature range: expanded from -20°C ~ 400°C to -46°C ~ 520°C
Zero-leakage operation:
Over 12 months of service, the valve maintained zero visible leakage, with no unplanned pipeline shutdowns.
78% improvement in operational efficiency:
The time required for a single isolation operation was reduced from 45 minutes to 10 minutes, resulting in over 200 hours of annual labor time savings.
Validated under extreme conditions:
The valve successfully withstood Siberian winter temperatures of -45°C and alternating exposure to 520°C high-temperature steam, with no structural deformation or sealing failure observed.
