A steam trap valve is a device designed on devices that require steam, which can automatically discharge condensate, air, and non condensable gases from the steam system and prevent steam from being discharged. Important Functions (1) Able to quickly remove condensate generated; (2) Prevent steam leakage; (3) Remove air and other non condensable gases. The necessity of using steam equipment to remove condensate and air: (1) Prevent water hammer: If there is condensate in the steam pipeline, it will be strongly impacted by the high-speed flowing steam on the pipe wall, valves, and steam equipment, causing damage or damage to the pipeline bends, valves, and steam equipment. (2) To prevent a decrease in the efficiency of steam using equipment: Steam using equipment (especially indirect heating devices) is aimed at effectively utilizing the latent heat of steam. Excessive condensate trapped in these devices comes into contact with the heating surface, reducing the heating area and uneven heating up and down, resulting in a significant decrease in equipment efficiency. (3) Prevent corrosion of steam inside equipment: Oxygen in water and air coming into contact with the equipment can cause chemical reactions, leading to rust corrosion. (4) Prevent damage to steam using equipment: Due to the different temperatures of steam and water, the condensed water inside the equipment generates temperature differences locally, causing temperature difference stress and equipment damage. Specific requirements for steam trap valves: (1) No steam leakage during the discharge of condensate; (2) It can eliminate all condensed water from any part of the steam system; (3) Capable of simultaneously discharging air and condensate; (4) Suitable for a wide range of pressures; (5) Easy to repair and maintain: simple structure with few moving parts; (6) High practicality: small size, light weight, long lifespan, low price, and no loss of emission capacity due to air and steam.
In industrial production, high-pressure ball valves play a crucial role, and damage to the sealing surface may lead to leakage and performance degradation. Therefore, measures must be taken to prevent and protect the sealing surface. 1. Proper Operation and Usage When operating high-pressure ball valves, it is essential to follow the correct operating procedures and technical requirements. Do not exceed the rated pressure and temperature range of the valve. Avoid over-tightening the valve to prevent damage to the sealing surface or premature wear. 2. Regular Inspection and Maintenance Regularly inspect the sealing surface of the ball valve, especially valves exposed to high-pressure and high-temperature environments. Remove any debris and dirt around the valve to ensure the sealing surface is in good working condition. 3. Select Appropriate Sealing Materials Choose suitable sealing materials according to the requirements of the working environment. For instance, in high-temperature or chemically corrosive environments, select sealing materials that are resistant to high temperatures and corrosion. Regularly inspect the wear and aging of sealing materials and promptly replace damaged seals. 4. Preventing Foreign Object Intrusion Install filters or screens to prevent foreign objects from entering the valve body and damaging the sealing surface. Avoid conducting messy operations around high-pressure ball valves to reduce the intrusion of external impurities. 5. Timely Repair and Replacement If damage or wear is found on the sealing surface, stop using it immediately and proceed with repairing or replacing the seals to prevent leaks from causing more serious issues. 6. Training and Education Provide training to operators to ensure they understand the working principles and proper operation methods of high-pressure ball valves, reducing the risk of seal surface damage due to operational errors. 7. Minimize Frequent Opening and Closing Reduce the frequency of opening and closing high-pressure ball valves because frequent operation increases wear and fatigue on the sealing surface, leading to premature failure. Where possible, take measures to minimize valve cycling, such as planning production schedules rationally or employing automated control systems. 8. Regular Cleaning and Maintenance Perform regular cleaning and maintenance on high-pressure ball valves to remove accumulated dirt and deposits inside the valve body, ensuring the valve operates smoothly and the sealing surface remains clean. Regular cleaning effectively reduces contamination and corrosion of the sealing surface, extending the lifespan of the seals. 9. Choose High-Quality Ball Valves Select high-quality high-pressure ball valve products to ensure that the design and manufacturing quality of the valves meet standard requirements and possess excellent performance and reliable sealing capabilities. Valves from DERVOS typically offer longer lifespan and better sealing effects, effectively...
Payment:
30% T/T When Order, 70% T/T Before ShipmentProduct Origin:
ChinaShipping Port:
Shanghai ChinaLead Time:
35~60 days Ex Works After Order ConfirmationMaterial:
Low Temperature Steel Ball Valve, A350 LF2Method of Operation:
Gearbox Operated Ball ValveThe Class 1500 4'' cryogenic ball valve is designed with extended stem for low temperature application. The valve is made of LF2 with fully welded body, butt weld end and gearbox operation.
Design Feature
-Fully welded & forged body
-Extended stem or bonnet
-Full port design and piggable
-Anti blow-out stem
-Antistatic function
- Automatic cavity relief
-Bi-directional seat and DBB design
-With stem and seat grease fittings
Quick Detail
|
Type |
Ball Valve |
|
Size |
4" |
|
Pressure |
ANSI 1500 |
|
Construction |
One-Piece Body, Fully Weld, Extended Stem or Bonnet, Full Port |
|
Connection |
Butt Weld |
|
Operation |
Gearbox Operated |
|
Body Material |
Low Temperature Steel A350 LF2 |
|
Design Code |
API 6D |
|
Pressure & Temp |
ASME B16.34 |
|
End to End Dimension |
ASME B16.10 |
|
End Connection |
ASME B16.25 |
|
Inspection |
API 598 |
|
Temperature Range |
-46℃~+200℃ |
|
Media |
Oil, Water, Gas |
Related Knowledge
What is the difference between full bore and reduced bore ball valve?
The internal diameter of a full bore ball valve is the same as the inner diameter of the pipe. The full bore ball valve has little resistance and pressure drop to the flow. Plus, the full bore ball valve is piggable.
However, the internal diameter of a reduced port (standard port) ball valve is smaller than the inner pipe size. Flow restriction caused by the reduced port will cause a pressure drop. And sometimes a pig to clean the pipe will get stuck in the reduced port ball valve.
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
The 4 inch cryogenic ball valve, designed as per API609, has many parts equipped RPTFE --It has the lowest coefficient of friction and the best corrosion resistance of any known plastic material, so that the valve can handle quite extreme situations.
3" 600LB ball valve is made according to API6D standard. The valve body is made of A182 F304. It has the structural characteristics of fixed ball, full bore, anti-fire and anti-static and anti-flying valve stem. Its connection mode is RF. And it has IP68 waterproof turbine box operation mode.
This ball valve, designed as per ASME B16.34, features two different connection ways--one side for RF and the other side NPT. The valve with floating ball, PTFE seat, SCS13 body and other features has an excellent sealing performance.
1" 1500LB gate valve is made according to ASME B16.34 standard. The valve body is made of A350 LF2. It has the structural characteristics of three piece, floating ball, full bore, anti-fireproof, anti-static, and anti-flying valve stem design. Its connection mode is RTJ. And it has lever operation mode.
4" 150LB butterfly valve is made according to API 609 standard. The valve body is made of A216 WCB. It has the structural characteristics of center line. Its connection mode is lug (UNC threaded hole, RF 125-250AARH). And it has lever (locking device) operation mode.
The 6 Inch PSB globe valve has 1500LB design pressure, butt weld end, and gearbox. The full bore globe valve is made of carbon steel WCB body and trim 5 material. Quick Detail Type Globe Valve Size 6'' Design Pressure Class 1500 Construction Pressure Seal Bonnet, Plug Type Disc, Rising Stem Connection Type Butt Weld Operation Type Bevel Gearbox Opearted Design Code BS 1873 End to End ASME B16.10 Connection End ASME B16.25 Pressure & Temperature ASME B16.34 Test & Inspection Standard API 598 Body Material Cast Steel WCB Trim Material Trim NO. 5 Temperature Range -29℃~+425℃ Application WOG Origin China Material & Dimension NPS DN Class 2 2 1/2 3 4 6 8 50 65 80 100 150 200 L(RF) L1(BW) 900LB 368 419 381 457 610 737 1500LB 368 419 470 546 705 832 2500LB 451 508 578 673 917 1022 L2(RTJ) 900LB 371 422 384 460 613 740 1500LB 371 422 473 549 711 841 2500LB 454 514 584 683 927 1038 H(Opne) 900LB 550 605 678 798 930 1230 1500LB 550 605 866 956 1260 1263 2500LB 560 720 755 1230 1791 2086 W 900LB 350 350 400 450 458 610* 1500LB 400 400 450 560 610* 610* 2500LB 400 450 560 310* 610* 760 Weight (RF) 900LB 78 108 102 142 400 960 1500LB 85 110 135 230 660 1590 2500LB 140 168 247 620 1500 3200 Weight (BW) 900LB 66 91 87 128 355 868 1500LB 77 101 122 209 595 1440 2500LB 100 118 180 438 1148 2594 *Manual gear operator is recommended No Part Name Carbon steel to ASTM Alloy steel to ASTM Stainless steel to ASTM WCB WC6 WC9 C5 CF8 CF8M CF3 CF3M 1 Body A216 WCB A217 WC6 A217 WC9 A217 C5 A351 CF8 A351 CF8M A351 CF3 A351 CF3M 2 Seat Ring A105 A182 F11 A182 F22 A182 F5 A182 F304 A182 F316 A182 F304L A182 F316L 3 Disc A105 A182 F11 A182 F22 A182 F5 A182 F304 A182 F316 A182 F304L A182 F316L 4 Stem A182 F6 A182 F304 A182 F304 A182 F316 A182 F304L A182 F316L 5 Disc nut A182 F6 A182 F304 A182 F304 A182 F316 A182 F304L A182 F316L 6 Cap SS Spiral Wound graphite or SS Spiral Wound PTFE 7 Body Seal Flexible Graphite+316 8 Adjustment Gasket F6 F6 F316 9 Stem packing Flexible Graphite+316 10 Gland Nut A194 2H A194 8 11 Gland Eyebolt A193 B7 A193 B8 12 Pin Carbon steel or Stainless Steel 13 Cap Nut Carbon steel or Stainless Steel 14 Gland A182 F6 A182 F304 A182 F316 A182 F304L A182 F316L 15 Gland Flange A216 WCB A351 CF8 16 Yoke A216 WCB A351 CF8 17 Stem Nut A439 D2 or B148-952A 18 Screw Carbon steel 19 Handwheel Ductile Iron or carbon steel 20 Name Plate Stainless steel or Aluminum 21 Washer Carbon steel 22 Nut Carbon steel or Stainless Steel Related Knowledge Why do we use pressure seal bonnet? Pressure sealed bonnet are often used for valves with high design pressure. The higher the internal pressure gets, the greater the sealing force beween body and bonnet become. For bolted bonnet valves, the body and bonnet are joined by studs and nuts with a gasket between the flange faces to facilitate sealing. However,as system pressure increases,the potential for leakage through the body and bonnet increases. But for pressure sealed valve, “bonnet take-up bolts” to pull the bonnet up and seal against the pressure seal gasket. That is why when pressure increase, the performance of pressure seal gasket between body and bonnet becomes better.
10’’ 300LB gate valve is made according to API 600 standard. The valve body is made of ASTM A217 C5 + STL. It has the structural characteristics of rising stem and bolt cover. The gate valve connected by flange has the operation mode of hand wheel.
DN150 PN25 floating ball valve is made according to ISO 17292 standard. The valve body is made of A351-CF8M. It has the structural characteristics of 2-piece, side entry, floating ball, full bore, flameproof, antistatic, anti-blowout stem. Its connection mode is RF. And it has lever operation mode.
DN15 PN40 gate valve is made according to EN ISO 15761 standard. The valve body is made of ASTM A182 F53. It has the structural characteristics of rigid wedge, full bore, rising stem, bolted cover. Its connection mode is EN1092-1 B1. And it has hand wheel operation mode.
6" 1500LB swing check valve is made according to API 6D standard. The valve body is made of WCB. It has the structural characteristics of swing type. It has BW connection mode.
The ductile iron gate valve has GGG50 body material and EPDM soft seat. The valve is designed with non-rising stem, RF connection and manual operation, used in fire water. Quick Detail Type Gate Valve Size DN300, DN400 Design Pressure PN10 Construction Non-rising Stem, Soft Seat ConnectionType Flange OperationType Handwheel Operation Body Material GGG50 TrimMaterial Stem 2Cr13, EPDM Seat Medium Water Origin China Hydrostatic Pressure Test Dimension Checking Packing
The stainless steel CF8 non return valve features in non slam type disc, ANSI 150 flange end, and full port design. Quick Detail Type Non Return Valve ( Check Valve) Size 8'' DesignPressure Class 150 Construction Non Slam Type Connection RF Flange Design & Manufacture ASME B16.34 End to End ASME B16.10 Connection ASME B16.5 Pressure & Temp ASME B16.34 Test & Inspection API 598 Body Material A351 CF8 Trim Material SS304 Media W.O.G. Available Modifications for Dervos Valves -Valve Pressure -Valve Size -Reduced Bore & Full Bore -Body & Trim Material (Disc, Seat, Pin, Spring) -End Connection (Flange, BW, SW, Thread, Wafer, Lug) -Available Operation (Bare Stem, With Actuators) -Available Counterweight -Available Cylinder -Customizing Coating -Customizing Packaging Related Knowledge What is non-slam check valve? Water hammer is a hydraulic phenomenon that undergoes an abrupt change in its rate of flow and are caused by sudden shutting or slamming. Water hammer will reduce process efficiency, cause valve damage, gasket joint leaks and other problems. The non-slam check valve is designed to reduce water hammer. An internal spring can prevent the disc from slamming close.The design of a non-slam check valve could eliminate pressure flutuations, vibration and damges. Plus, the disc and spring experience minimal wear over time, which will largely extend the service lives of non-slam check compared to swing check valve.
