6" 300LB Axial Flow Check valve is made according to API594 standard. The valve body is made of SS2205. It has the structural characteristics of Silent type. Its connection mode is Wafer Type.
Payment:
30% when order confirmed, 70% before shipmentProduct Origin:
ChinaColor:
CustomizationShipping Port:
Shanghai, ChinaLead Time:
30~60 days Ex Works after order confirmationMaterial:
SS2205
|
Type |
Axial Flow Check Valve |
|
Size |
6" |
|
Pressure |
300LB |
|
Connection |
Wafer |
|
Body Material |
SS2205 |
|
Design Norm |
API 594 |
|
Face to Face Dimensions |
API 594 |
|
End Flange Dimensions |
ANSI B16.5 |
|
Test & Inspection Code |
API 598 |
|
Temperature |
-29 ~ 200°C |
|
Applicable Medium |
Water, Oil and Gas |
1. Valve disc has no impact action, smooth opening and closing action, almost no "knocking" sound, suitable for occasions with strict noise requirements;
2. The valve disc and seat are precisely matched, and can be equipped with metal seals or soft seals, with reliable sealing and no leakage.
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
