Payment:
30% when order confirmed, 70% before shipmentProduct Origin:
chinaColor:
CustomizationShipping Port:
Shanghai, ChinaLead Time:
30~60 days Ex Works after order confirmationMaterial:
ASTM A105NMethod of Operation:
hand wheelDN80 PN160 Forged Floating Ball Valve is made according to EN 12266 standard. The valve body is made of ASTM A105N. Its connection mode is LG. And it has Hand Wheel operation mode.
|
Type |
Forged Floating Ball Valve |
|
Size |
DN80 |
|
Pressure |
PN160 |
|
Connection |
LG |
|
Operation |
Hand Wheel |
|
Body Material |
ASTM A105N |
|
Design Norm |
ISO 14313 |
|
Face to Face |
MFR’S |
|
End connection |
LG |
|
Test & Inspection Code |
EN 12266 |
|
Temperature |
-29 ~ 120°C |
|
Applicable Medium |
Water, Oil and Gas |
1.Forged A105N carbon steel body ensures excellent mechanical strength and reliable performance in PN160 high-pressure applications.
2.Floating ball valve design tested to EN 12266 leakage grade LG provides tight shutoff and dependable sealing integrity.
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
