The tilting disc check valve is a common type of valve used in pipeline systems to prevent reverse flow of the medium. It typically consists of components such as the valve body, disc, spring, and sealing gasket. The working principle of the tilting disc check valve is based on the design of the disc: the disc is positioned at an angle, allowing the medium to flow smoothly through the valve in the forward direction, while swiftly closing the valve in the event of reverse flow, thereby preventing backflow of the medium. One of the characteristics of the tilting disc check valve is its simple structure. Due to the fewer components and compact layout, manufacturing and maintenance are relatively easy. Additionally, the tilting disc check valve has the capability of quick closure. When there is a change in the flow direction of the medium, the disc promptly responds and closes the valve, effectively preventing backflow of the medium and maintaining the normal operation of the pipeline system. Another significant feature is its excellent sealing performance. The tilting disc check valve employs devices such as springs to assist in closing the disc, ensuring effective sealing of the valve in the closed position, thus preventing medium leakage and safeguarding the safe operation of the pipeline system. Furthermore, tilting disc check valves are typically manufactured using corrosion-resistant materials, enabling them to operate stably in corrosive media over the long term. Another notable feature of the tilting disc check valve is its wide range of applications. It is suitable for various media, including liquids, gases, and steam, and is widely used in industries such as water supply, drainage, chemical, and petroleum. Whether in low-pressure systems or high-pressure systems, tilting disc check valves can reliably prevent medium backflow, protecting the safety operation of pipelines and equipment. In summary, the tilting disc check valve plays a crucial role in pipeline systems due to its characteristics of simple structure, rapid closure, excellent sealing performance, corrosion resistance, and wide applicability. When designing and selecting valves, considering factors such as the working pressure of the pipeline system, characteristics of the medium, and operating environment, choosing the appropriate tilting disc check valve can effectively enhance the safety and stability of the pipeline system.
The installation requirements of fully welded ball valves in underground pipelines are crucial, as the unique characteristics of the underground environment pose higher demands on the performance and safety of the valves. Proper installation not only ensures the normal operation of the valves but also prolongs their service life and enhances the safety and reliability of the pipeline system. The following are the specific requirements for installing fully welded ball valves in underground pipelines: 1. Selecting the appropriate valve type When installing fully welded ball valves in underground pipelines, it is necessary to choose the appropriate valve type based on the operating conditions and fluid characteristics of the pipeline system. Fully welded ball valves, with advantages such as simple structure and reliable sealing, are suitable for high-pressure, high-temperature, and corrosive fluid applications in pipeline systems. 2. Underground burial depth consideration When installing fully welded ball valves, it is imperative to consider the depth of underground burial. Typically, the burial depth of underground pipelines should comply with relevant standards and specifications to ensure the valves are positioned securely while facilitating maintenance and operation. 3. Corrosion protection measures The dampness of the underground environment and the presence of chemicals in the soil can lead to corrosion and damage to valves. Therefore, when installing fully welded ball valves, it is necessary to implement appropriate corrosion protection measures. This includes selecting valves manufactured from corrosion-resistant materials and applying corrosion-resistant coatings to the valves to extend their service life. 4. Sealing performance requirements Fully welded ball valves in underground pipeline systems must possess excellent sealing performance to prevent fluid leakage and contamination of groundwater sources. During installation, it is imperative to ensure that the valve's sealing components are intact and properly installed to ensure that the sealing performance meets design requirements. 5. Consideration of groundwater level fluctuations Fluctuations in groundwater levels may affect the operational status and safety of fully welded ball valves. When selecting installation locations, it is essential to consider the range of groundwater level fluctuations and implement corresponding waterproofing measures to prevent groundwater from affecting the valves. 6. Regular inspection and maintenance The underground environment has a significant impact on fully welded ball valves; therefore, regular inspection and maintenance of the valves are essential. Inspection tasks include assessing the sealing performance of the valves, checking the condition of moving parts, evaluating the effectiveness of corrosion protection measures, and promptly addressing any issues to ensure the safe operation of the valves. When installing fully welded ball valves in unde...
We are delighted to announce that our company is on the brink of a new beginning - the acquisition of a new office space. This marks a fresh start for our company's development, and we eagerly anticipate crafting a brighter future in this new environment. The selected location enjoys excellent geographic positioning, convenient transportation, and a pleasant environment. The choice of our new office space has been meticulously considered, aiming to provide our employees with a spacious and comfortable working environment while offering ample support and motivation for the company's development. Starting from April 15, 2024, our office address will be changed to: [Unit 3104, Channel Pearl Plaza, No.99 Yilan Road, Siming District, 361008, Xiamen City, Fujian Province, China]。This relocation is not only a natural choice for the continued development of our company, but also a testament to our confidence and aspirations for the future. The utilization of the new premises will further enhance internal collaboration and communication within the company, ignite the creativity and vitality of our team, and elevate our efficiency and service standards. We aim to deliver even higher-quality products and services to our customers and partners as a result. Finally, we would like to express our heartfelt gratitude for your long-standing support and trust in our company. We believe that this new beginning will bring forth fresh hope and opportunities. We will continue to uphold the principle of 'Customer First, Innovative Development', striving for excellence and working towards our long-term corporate goals. Let us join hands and work together to create a brighter future.
The 1 1/2inch 1500LBglobe valve,made of A105N are best suited for throttling application at high pressure and temperature.
Payment:
30% when order confirmed, 70% before shipmentProduct Origin:
ChinaColor:
CustomizationShipping Port:
Shanghai, ChinaLead Time:
30~60 days Ex Works after order confirmationMaterial:
A105NMethod of Operation:
HandwheelQuick Detail
|
Type |
Globe Valve |
|
Nominal Diameter |
1 1/2 Inch |
|
Nominal Pressure |
1500LB |
|
Construction |
Pressure Seal Bonnet |
|
Connection |
SW |
|
Design & Manufacture |
B16.34 |
|
SW Dimension |
ASME B16.11 |
|
Test & Inspection |
API598 |
|
Body Material |
A105N |
|
Disc Material |
304+STL |
|
Temp. Range |
-29～38°C |
|
Media |
Oil, Gas |
Features
·Proven pressure seal design.
·Body guided disc eliminates side thrust and provides longer disc, seat and body life.
·Body made of superior strength forgings and optional cast steel.
·Optional live-loading of packing.
·Other sizes and pressure classes available.
Technical Drawing
Dimension Check
Witness Tests
Our Service
A good customer service is as valuable as product itself. In Dervos, we will offer a full range of customer service to make you feel easy when doing business with us.
Providing weekly production report
When production begins, you will get production report weekly, so that you can have good command of product status and report to your customer at the meantime.
Offering warranty of 18 months
18 months warranty period will be offered after shipment, no concern to purchase valve from Dervos.
Providing solutions within 3-days for complaints
All the complaints will be solved within 3 days, in this case, you can timely reply and solve problems for your customer, to relax them even when complaints happening.
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
The 6 Inch PSB globe valve has 1500LB design pressure, butt weld end, and gearbox. The full bore globe valve is made of carbon steel WCB body and trim 5 material. Quick Detail Type Globe Valve Size 6'' Design Pressure Class 1500 Construction Pressure Seal Bonnet, Plug Type Disc, Rising Stem Connection Type Butt Weld Operation Type Bevel Gearbox Opearted Design Code BS 1873 End to End ASME B16.10 Connection End ASME B16.25 Pressure & Temperature ASME B16.34 Test & Inspection Standard API 598 Body Material Cast Steel WCB Trim Material Trim NO. 5 Temperature Range -29℃~+425℃ Application WOG Origin China Material & Dimension NPS DN Class 2 2 1/2 3 4 6 8 50 65 80 100 150 200 L(RF) L1(BW) 900LB 368 419 381 457 610 737 1500LB 368 419 470 546 705 832 2500LB 451 508 578 673 917 1022 L2(RTJ) 900LB 371 422 384 460 613 740 1500LB 371 422 473 549 711 841 2500LB 454 514 584 683 927 1038 H(Opne) 900LB 550 605 678 798 930 1230 1500LB 550 605 866 956 1260 1263 2500LB 560 720 755 1230 1791 2086 W 900LB 350 350 400 450 458 610* 1500LB 400 400 450 560 610* 610* 2500LB 400 450 560 310* 610* 760 Weight (RF) 900LB 78 108 102 142 400 960 1500LB 85 110 135 230 660 1590 2500LB 140 168 247 620 1500 3200 Weight (BW) 900LB 66 91 87 128 355 868 1500LB 77 101 122 209 595 1440 2500LB 100 118 180 438 1148 2594 *Manual gear operator is recommended No Part Name Carbon steel to ASTM Alloy steel to ASTM Stainless steel to ASTM WCB WC6 WC9 C5 CF8 CF8M CF3 CF3M 1 Body A216 WCB A217 WC6 A217 WC9 A217 C5 A351 CF8 A351 CF8M A351 CF3 A351 CF3M 2 Seat Ring A105 A182 F11 A182 F22 A182 F5 A182 F304 A182 F316 A182 F304L A182 F316L 3 Disc A105 A182 F11 A182 F22 A182 F5 A182 F304 A182 F316 A182 F304L A182 F316L 4 Stem A182 F6 A182 F304 A182 F304 A182 F316 A182 F304L A182 F316L 5 Disc nut A182 F6 A182 F304 A182 F304 A182 F316 A182 F304L A182 F316L 6 Cap SS Spiral Wound graphite or SS Spiral Wound PTFE 7 Body Seal Flexible Graphite+316 8 Adjustment Gasket F6 F6 F316 9 Stem packing Flexible Graphite+316 10 Gland Nut A194 2H A194 8 11 Gland Eyebolt A193 B7 A193 B8 12 Pin Carbon steel or Stainless Steel 13 Cap Nut Carbon steel or Stainless Steel 14 Gland A182 F6 A182 F304 A182 F316 A182 F304L A182 F316L 15 Gland Flange A216 WCB A351 CF8 16 Yoke A216 WCB A351 CF8 17 Stem Nut A439 D2 or B148-952A 18 Screw Carbon steel 19 Handwheel Ductile Iron or carbon steel 20 Name Plate Stainless steel or Aluminum 21 Washer Carbon steel 22 Nut Carbon steel or Stainless Steel Related Knowledge Why do we use pressure seal bonnet? Pressure sealed bonnet are often used for valves with high design pressure. The higher the internal pressure gets, the greater the sealing force beween body and bonnet become. For bolted bonnet valves, the body and bonnet are joined by studs and nuts with a gasket between the flange faces to facilitate sealing. However,as system pressure increases,the potential for leakage through the body and bonnet increases. But for pressure sealed valve, “bonnet take-up bolts” to pull the bonnet up and seal against the pressure seal gasket. That is why when pressure increase, the performance of pressure seal gasket between body and bonnet becomes better.
The 1 1/2inch 1500LB globe valve,made of one kind of alloy steel F22, is the best answer to working conditions under high pressure and temperature .
2" 150LB butterfly valve is made according to API609 standard. The valve body is made of WCB. It has the structural characteristics of double eccentricity, high performance. Its connection mode is LUG. And it has lever operation mode.
The 16 inch cast steel gate valve with gearbox and 600LB RF flange is designed as per API 600. The bolted bonnet gate valve features in rising stem, resilient wedge and metal seat. Quick Detail Type Gate Valve Size 16" Pressure Class600 Construction Bolted Bonnet, Rising Stem, OS&Y, Flexible Wedge, Metal Seat Connection RF Flange Operation Gearbox Design Code API 600 Face to Face ASME B16.10 Flange End ASME B16.5 Pressure & Temp ASME B16.34 Test & Inspection API 598 Body Material A216 WCB TrimMaterial Trim 5 Temperature Range -29℃~+425℃ Medium Water, Oil and Gas Origin China Dimension & Material Class 600 NPS in 2 2 1/2 3 4 6 8 10 12 14 16 18 20 24 DN mm 50 65 80 100 150 200 250 300 350 400 450 500 600 L-L1 (RF-BW) in 11.5 13 14 17 22 26 31 33 35 39 43 47 55 mm 292 330 356 432 559 660 787 838 889 991 1092 1194 1397 L2 (RTJ) in 11.625 13.125 14.125 17.125 22.125 26.125 31.125 33.125 35.125 39.125 43.125 47.25 55.375 mm 295 333 359 435 562 664 791 841 892 994 1095 1200 1407 H (OPEN) in 18.625 21.75 23.375 28 1/16 38 3/16 44 3/16 52.375 59 13/16 68.125 72.25 90.125 98 13/16 119 mm 474 553 593 713 970 1122 1330 1519 1730 1835 2290 2510 3022 W in 9.875 9.875 11 13/16 13.75 19 11/16 22 1/16 28.375 24 24 24 24 30 30 mm 250 250 300 350 500 560 720 610* 610* 610* 610* 760* 760* WT (kg) RF 41 58 88 131 253 413 623 784 1288 1820 2150 2540 4080 BW 35 50 68 104 208 328 496 637 1120 1448 1828 2201 3360 *Manual gear operator is recommended No Part Name Carbon steel to ASTM Alloy steel to ASTM Stainless steel to ASTM WCB LCB WC6 WC9 C5 CF8 CF8M CF3 CF3M 1 Body A216 WCB A350 LCB A217 WC6 A217 WC9 A217 C5 A351 CF8 A351 CF8M A351 CF3 A351 CF3M 2 Seat Ring A105 A350 LF2 A182 F11 A182 F22 A182 F5 A182 F304 A182 F316 A182 F304L A182 F316L 3 Wedge A216 WCB A350 LCB A217 WC6 A217 WC9 A217 C5 A351 CF8 A351 CF8M A351 CF3 A351 CF3M 4 Stem A182 F6 A182 F6 A182 F304 A182 F304 A182 F316 A182 F304L A182 F316L 5 Bonnet nut A194 2H A194 4 A194 7 A194 8 6 Bonnet bolt A193 B7 A320 L7 A193 B16 A193 B8 7 Gasket SS Spiral Wound graphite or SS Spiral Wound PTFE 8 Bonnet A216 WCB A352 LCB A217 WC6 A217 WC9 A217 C5 A351 CF8 A351 CF8M A351 CF3 A351 CF3M 9 Backseat bushing A182 F6 A182 F6 A182 F304 A182 F304 A182 F316 A182 F304L A182 F316L 10 Stem packing Graphite or PTFE 11 Lantern A182 F6 A182 F6 A182 F304 A182 F304 A182 F304 A182 F304 A182 F316 A182 F304L A182 F316L 12 Gland Nut A194 2H A194 8 13 Gland Eyebolt A193 B7 A193 B8 14 PIN Carbon steel or Stainless Steel 15 Gland A182 F6 A182 F304 A182 F316 A182 F304L A182 F316L 16 Gland Flange A216 WCB A351 CF8 17 Stem Nut A439 D2 or B148-952A 18 Nipple Carbon steel or Stainless Steel 19 Retaining Nut Carbon steel 20 Hand Wheel Ductile Iron or carbon steel 21 Name Plate Stainless steel or Aluminum 22 H.W.Lock Nut Carbon steel
Made of stainless steel, the cryogenic gate valve has extended bonnet, reduced bore, non-rising handwheel, socket weld connection, complying with API 602. Quick Detail Type Gate Valve Size 1'' Design Pressure ANSI 1500 Construction Extended Stem, Bolted Bonnet, Solid Wedge ConnectionType Socket Weld (SW) OperationType Handwheel Operation Body Material A182 F316L TrimMaterial SS316L Design Code ASME B16.34 Face to Face ASME B16.10 End Connection ASME B16.11 Medium Water, Oil and Gas Origin China Available Modifications for Dervos Valves -Design Pressure -Nominal Diameter -Body Material & Trim Material -Material & Type for Packing and Gasket -Valve Operation Type -Modifications of End Connection -Available Extended Stem or Bonnet -Available By-Pass Valve -Customized Coatings & Packaging Related Knowledge Why do we use extended stem for cryogenic valves? The cryogenic valves are mainly used in low temperature liquid media, like liquefied natural gas and petroleum products. The reasons why we use extended stem for cryogenic valves are as below: 1.To maintain the temperature of stem packing in a proper level, since the very low temperature will influnce the sealing function of stem pakcing. 2.To prevent the heat outside from entering the valve and cause energy loss to the application 3.The long stem structure facilitates the quick replacement of the valve's main part through the valve cover. 4.To prevent the parts (like handwheel) over stem from freezing
China Flanged Ball Valve Supplier Offers Carbon Steel Flanged Ball Valve, ASTM A105N, Class 600 LB, 1 Inch, BS 5351, Free Floating Ball, Side Entry.
You can found this valve in a various high performance applications such as steam, chilled water, gasoline, oil, jet fuels, natural gas, utility lines, process lines and in industries.
ASME B16.34 Y type Strainer Flat Flange Connection Bolt Cover ASTM A182 F316 ASTM A351 CF8M Gasket SS316 + Flexible Graphite Screens SS316 Drain Plug 3/4” NPT Bolt Bonnet B8M 8M 6 inch 150LB 8inch 150LB Design and manufacture ASME B16.34 Face to Face Dimension ASME B16.10 Flange Dimension ASME.B16.5 Test and Inspect API598 Quick Detail Type Y Type Strainer Size 6 inch 8 inch Pressure CL150 Construction Bolt Cover Connection FF Operation Mode / Body Material CF8M Cover F316 Design & Manufacture ASME B16.34 End to End ASME B16.10 End Connection ASME B16.5 Inspection API 6D, API 598 Temperature Range -29℃~+538℃ Medium Oil, Water, Gas
24" 150LB Wafer check valve is made according to API 594 standard. The valve body is made of WCB. It has the structural characteristics of double disc. Its connection mode is lug type.
2" 600LB check valve is made according to BS1868 standard. The valve body is made of A216 WCB. It has the structural characteristics of lifting type, bolt cover and body valve seat. Its connection mode is RF.
1/2" PN100 needle valve is made according to ASME B16.34 standard. The valve body is made of A105. It has the structural characteristics of straight-through. Its connection mode is Male/Female NPT. And it has lever operation mode.
DN250 PN10 check valve body is made of A216 WCB+STL. It has the structural characteristics of heavy hammer on both sides and flange type. Its connection mode is RF.
